filling packing machine

Granular pre-made bag packaging machine

all kinds of pre-made pouches such as flat and stand-up pouches (with/ without zip). PLC controller, HMI system, fault indication on the touch screen. only about 10 minutes to change different pouches.

Share this:
  • Product Description
Product Description

Applications for Granule Weighing and Filling Production Line:

All kinds of granules, like washing powder, rice, seeds, sugar, fodder, sesame seeds, etc.

Main Features of Granule Weighing and Filling Production Line:

1. A wide range of pouches: all kinds of pre-made pouches such as flat and stand-up pouches (with/ without zip).

2. Easy to operate: PLC controller, HMI system, fault indication on the touch screen.

3. Easy to adjust: only about 10 minutes to change different pouches.

4. Frequency control: speed can be adjusted by frequency conversion within the range.

5. High Automation: unmanned in weighing and packing process, machine alarm automatically when failure.

Safety and Hygiene of Granule Weighing and Filling Production Line:

1. No pouch/ incorrect pouch opening-no fill-no seal, machine alarm.

2. Machine alarm and stop when the inadequate air pressure.

3. Safety guards with safety-switches, machine alarm and stop when the safety guards are opened.

4. Hygienic construction, the product contact parts are adopted sus304 stainless steel.

5. Imported engineering plastic bearings, no need to oil, no contamination.

6. Oil-free vacuum pump, avoid the pollution of the production environmental.

Main Specifications of Granule Weighing and Filling Production Line:

Production Line

Granule Weighing and Filling Production Line

Bag types

Standup bag, Portable bag, Zipper bag, 4-side sealing bag, 3-side sealing bag, paper bag, etc., and all kinds of compound bags

Bag sizes

W: 80-320mm L:100-430mm

Filling range

5-1500g

Packing speed

25-45bags/min (depended on the product and filling weight)

Auxiliary Equipment

4/6-head Weigher, Bucket Conveyor, Working Platform

Package accuracy

Error≥±1%

Total power

3kw

Compress air requirement

≥0.4 m3/min
