filling packing machine

Liquid & Paste pre-made bag packaging machine

All kinds of liquid and think-liquid (sauce), fruit juice, seasoning sauce, tomato sauce, peanut butter, jam, chili sauce, hand sanitizer, liquid detergent and so on. PLC controller and color touch-screen, fault indication on the touch screen.

Share this:
  • Product Description
Product Description

Applications for Liquid & Thick Liquid Fill-Seal Production Line:

All kinds of liquid and think-liquid (sauce), fruit juice, seasoning sauce, tomato sauce, peanut butter, jam, chili sauce, hand sanitizer, liquid detergent and so on.

Main Features of Liquid & Thick Liquid Fill-Seal Production Line:

1. A wide range of pouches: all kinds of pre-made pouches such as flat and stand-up pouches (with/ without zip).

2. Wash-down: direct water-washing the machine surface, so timely clean up the corrosive material, to enhance the hygienic and safety, to prolong the useful life.

3. Easy to operate: PLC controller and color touch-screen, fault indication on the touch screen.

4. Easy to adjust: only about 10 minutes to change different pouches.

5. Frequency control: speed can be adjusted by frequency conversion within the range.

6. High Automation: unmanned in weighing and packing process, machine alarm automatically when failure.

7. Waterproof design: the machine surface can be washed down, so easy cleaning, and longer useful life.

Main Specifications of Liquid & Thick Liquid Fill-Seal Production Line:

Production Line

Liquid & Thick Liquid Fill-Seal Production Line

Bag types

Standup bag, Portable bag, Zipper bag, 4-side sealing bag, 3-side sealing bag, paper bag, etc., and all kinds of compound bags

Bag sizes

W: 80-320mm L:100-430mm

Filling range

5-1500g

Packing speed

25-45bags/min (depended on the product and filling weight)

Auxiliary Equipment

Liquid filling machine

Package accuracy

Error≥±1%

Total power

2.3kw

Compress air requirement

≥0.4 m3/min
