Multi head weigher type pre-made made bag packaging machine

Applications for Solid Weigh-Fill-Seal Production Line:

All kinds of grains and solids, like candy, nuts, raisins, peanuts, melon seeds, nuts, potato chips, chocolate, biscuits and so on.

Main Features of Solid Weigh-Fill-Seal Production Line:

1. A wide range of pouches: all kinds of pre-made pouches such as flat and stand-up pouches (with/ without zip).

2. Easy to operate: PLC controller, HMI system, fault indication on the touch screen.

3. Easy to adjust: only about 10 minutes to change different pouches.

4. Frequency control: speed can be adjusted by frequency conversion within the range.

5. High Automation: unmanned in weighing and packing process, machine alarm automatically when failure.

Safety and Hygiene of Solid Weigh-Fill-Seal Production Line:

1. No pouch/ incorrect pouch opening-no fill-no seal, machine alarm.

2. Machine alarm and stop when the inadequate air pressure.

3. Safety guards with safety-switches, machine alarm and stop when the safety guards are opened.

4. Hygienic construction, the product contact parts are adopted sus304 stainless steel.

5. Imported engineering plastic bearings, no need to oil, no contamination.

6. Oil-free vacuum pump, avoid the pollution of the production environmental.

Main Specifications of Solid Weigh-Fill-Seal Production Line:

Production Line	Solid Weigh-Fill-Seal Production Line
Bag types	Standup bag, Portable bag, Zipper bag, 4-side sealing bag, 3-side sealing bag, paper bag, etc., and all kinds of compound bags
Bag sizes	W: 80-320mm L:100-430mm
Filling range	5-1500g
Packing speed	25-68bags/min (depended on the product and filling weight)
Auxiliary Equipment	Multi-head Weigher, Bucket Conveyor, Working Platform
Package accuracy	Error≥±1%
Total power	4.5kw
Compress air requirement	≥0.4 m3/min
