filling packing machine

Powder pre-made bag packaging machine

all kinds of pre-made pouches such as flat and stand-up pouches (with/ without zip). PLC controller, HMI system, fault indication on the touch screen. Easy to adjust: only about 10 minutes to change different pouches.

Share this:
  • Product Description
Product Description

Applications for Powder Filling and Sealing Production Line:

All kinds of powder, like milk powder, coffee, spices, additives etc.

Main Features of Powder Filling and Sealing Production Line:

1. A wide range of pouches: all kinds of pre-made pouches such as flat and stand-up pouches (with/ without zip).

2. Easy to operate: PLC controller, HMI system, fault indication on the touch screen.

3. Easy to adjust: only about 10 minutes to change different pouches.

4. Wash-down: direct water-washing the machine surface, so timely clean up the corrosive material, to enhance the hygienic and safety, to prolong the useful life.

5. Dust removing device: to avoid the powder affecting the sealing.

6. Frequency control: speed can be adjusted by frequency conversion within the range.

7. High Automation: unmanned in weighing and packing process, machine alarm automatically when failure.

Safety and Hygiene of Powder Filling and Sealing Production Line:

1. No pouch/ incorrect pouch opening-no fill-no seal, machine alarm.

2. Machine alarm and stop when the inadequate air pressure.

3. Safety guards with safety-switches, machine alarm and stop when the safety guards are  opened.

4. Hygienic construction, the product contact parts are adopted sus304 stainless steel.

5. Imported engineering plastic bearings, no need to oil, no contamination.

6. Oil-free vacuum pump, avoid the pollution of the production environmental.

Main Specifications of Powder Filling and Sealing Production Line:

Production Line

Powder Filling and Sealing Production Line

Bag types

Standup bag, Portable bag, Zipper bag, 4-side sealing bag, 3-side sealing bag, paper bag, etc., and all kinds of compound bags

Bag sizes

W: 80-320mm L:100-430mm

Filling range

5-1500g

Packing speed

25-45bags/min (depended on the product and filling weight)

Auxiliary Equipment

Auger filler, auger conveyor

Package accuracy

Error≥±1%

Total power

3.6kw

Compress air requirement

≥0.4 m3/min
